Danfoss 132B0254 Frequency Converter
Description:
Description: Danfoss
Product No. :132B0254
https://www.achievers-automation.com More Products
Reliable Industrial Component Sourcing for Enterprises
This industrial automation component is supplied for enterprise procurement .Made-to-order and forward delivery are supported, with pricing quoted per inquiry.
To reduce sourcing risk, each order is handled individually with support for model confirmation, condition clarification, and lead time estimation before order placement. Clear quotation terms and consistent communication are provided to help partners manage expectations and complete transactions with confidence. Additional verification or clarification is available when required, supporting professional procurement and long-term cooperation.
The Danfoss 132B0254 is a single-phase input frequency converter designed for efficient AC motor control, with a rated power of 0.75 kW (1 HP) and a maximum output current of 3.8 A. As part of Danfoss’s VLT® Micro Drive lineup, it features a compact, space-saving book-style design that allows side-by-side mounting without derating, effectively optimizing control cabinet space utilization. The product is supplied without a control panel, but compatible LCD control panels (with or without potentiometer) are available as optional accessories. It supports flexible parameter configuration and integrates practical functions such as automatic energy optimization (AEO), automatic motor tuning, and a built-in RFI filter, ensuring efficient, reliable motor control while minimizing energy consumption.
Detail:
|
Specification Category
|
Details
|
|
Model
|
132B0254
|
|
Brand
|
Danfoss
|
|
Product Type
|
Frequency Converter (Variable Speed Drive, VSD/VFD)
|
|
Product Series
|
Danfoss VLT® Micro Drive Series
|
|
Rated Power (Normal Duty)
|
0.75 kW (1 HP)
|
|
Input Phase
|
Single Phase
|
|
Input Voltage Range
|
200 V AC - 240 V AC, 50/60 Hz
|
|
Maximum Output Current
|
3.8 A (Normal Duty)
|
|
Output Frequency Range
|
0 - 200 Hz (VVC+ mode); 0 - 400 Hz (U/F mode)
|
|
Communication Protocol
|
Modbus RTU, Danfoss FC Protocol
|
|
Protection Rating
|
IP20
|
|
Standards Compliance
|
ISO 14001, RoHS, WEEE, CE, UL, C-tick
|
|
Parameter Name
|
Specifications
|
|
Mounting Type
|
Panel Mount, Surface Mount
|
|
Dimensions (L×W×D)
|
75mm × 130mm × 168mm
|
|
Operating Temperature Range
|
0°C to +50°C (no condensation)
|
|
Storage Temperature Range
|
-25°C to +70°C (no condensation)
|
|
Relative Humidity
|
5% to 90% RH (non-condensing)
|
|
Power Dissipation
|
38.0 W - 42.0 W
|
|
Control Panel
|
Not included; optional LCD panels available
|
|
Parameter Setting Method
|
Optional control panel or Danfoss VLT® Motion Control Tool (PC)
|
|
Built-In Components
|
RFI filter (Class A), braking chopper, electronic thermal relay
|
|
Pollution Degree
|
2
|
Brand
